3/4" Velan W04-2074W-02TS Socket Weld Globe Valve, Class 800, A105 Body, Welded Bonnet, API Trim 5

Highlights

• Nominal Pipe Size (NPS): 3/4"
• Forged steel globe valve manufactured by Velan, model W04-2074W-02TS
• ASTM A105 forged carbon steel body for high-pressure industrial service
• ASME Class 800 pressure rating
• Socket weld (SW) ends provide secure, leak-resistant piping connections
• Welded bonnet design offers maximum pressure integrity and enhanced leak protection
• API Trim 5 with Stellite® 6 hardfaced seat and disc plus a Type 410 stainless steel stem for superior wear resistance
• Globe valve design delivers accurate flow regulation and dependable shutoff performance
• Manufactured to API 602, ASME B16.34, and tested to API 598
• Ideal for steam, condensate, refinery, petrochemical, power generation, oil & gas, and other demanding high-pressure process applications.
